| Details as following |
| MODEL | WYCS5-320 |
| Chutes(channels) | 5(320) |
| Sorting accuracy(%) | ≥99.9 |
| Carryover rate (bad:good) | ≥12:1 |
| Capacity(T/h) | 3 |
| Voltage | 180-240V/50Hz |
| Power supply(kw) | 2.6 |
| Work Air Pressure(Mpa) | 0.2-0.3 |
| Air consumption(L/min) | 1300-2800 |
| Air supply(Mpa) | 0.6--0.8 |
| Dimension(L*W*H) mm | 2204*1560*1860 |
| Weight(kgs) | 900 |
| Package | Plywood case |
| Package Size mm | 2500*1680*2060 |
Applications:
Dehydrated vegetables, plastic tablets, used glass, Chinese herbal medicine pieces, dried chili, garlic cloves, dried shrimps, miscellaneous grains, etc.; uniform size and non-round granular materials.
Peanuts, soybeans, lotus seeds, pine nuts, macadamia nuts, plastic bottle flakes, quartz sand, ore, Chinese herbal medicine, scrap metal, salt water bottle tablets, etc.; round granular materials, irregular shape and sorting environment, more dusty materials.
concave materials such as cashews.
Walnut, nut shell kernels, miscellaneous, foreign matter sorting models.
Special machine for aquatic products such as shrimp and dried small fish
Special machine for vegetable materials such as beans and peas.
Customization:
- Customizable Branding - Add your company's logo or name to the product
- Custom Sorting Options - Our team can customize the color sorting options to fit your specific needs
- Customizable Hopper Size - We can adjust the hopper size to fit the amount of grain you need to sort
- Customizable Chute Design - Our team can help design a chute that fits the specific space requirements of your operation
Color Sorter Grain is a crucial step in the grain industry. The WENYAO Grain Color Sorter is a reliable and efficient solution that can help increase productivity and profits. Contact us today to learn more about our product customization services.
Support and Services:
The Grain Color Sorter product comes with the following technical support and services:
- Installation and setup assistance
- Training on how to use the product
- 24/7 technical support via phone or email
- Regular maintenance and inspection services
- Replacement of defective parts
- Software updates and upgrades
Packing and Shipping:
Product Packaging:
The Grain Color Sorter product will be securely packaged in a sturdy cardboard box to ensure safe transportation. The product will be wrapped in bubble wrap and other protective materials to prevent any damage during shipping. The package will also include an instruction manual and any necessary accessories.
Shipping:
The Grain Color Sorter product will be shipped via a reliable courier service. The shipping cost will be calculated based on the destination and weight of the package. The estimated delivery time will be provided at the time of purchase. Customers will receive a tracking number to track the shipment until it arrives at their doorstep. It is important to provide accurate shipping information to avoid any delays or misdelivery.
FAQ:
1. How to use the machine?
We will supply the Installation instructions or video and our engineers will train your operators.
2. How long about the guarantee period?
One year. And we supply lifelong software upgrade services for our customers.
3. Can you supply the air compressor, air tank and air filters?
Yes, we can provide above equipments, our standard offer includes color sorter machine with air compressor, air tank and filters.
4. Is oversea service available?
Yes, our engineers could go abroad when required.
5.How to calculate Installation personnel cost?
On condition that customer requires to install, our company would like to send engineer to guide for installation, then customer should to pay the cost, including transaction of Engineer's visa, transportation(air) for go abroad. and accommodation, local transportation and security when the Engineer arrived.
Intelligent Holographic Flash Camera Compatible with CMOS or CCD image sensors
Flexible switch between visible lens or infrared lens35K high-speed imaging +350 million pixel ultra-clear resolution
LED light source
Flexible Light Source Configuration: For different raw
material, the Color LED illumination system can choose use different spectrum for the illumination to increase the contrast and increase the precision of information
acquisition. The LED illumination system has the cooling system, so the system has the long lifetime, low energy consumption and high performance.
Dedicated Image Processing Algorithm According to the characteristics of material, use the shape and color combination algorithm; For materials with
complex colors, the machine sorts materials more directly and accurately by using HSV-changed color space sorting method.
High-Quality Solenoid Valve
Use High-quality,high-frequency,long service life ejecter, super low air consumption guaranteed the biggest capacity, excellent rejection output. For the different sizes and
characteristics of material particle, use the solenoid valve of different sizes.
Simple Operation
Simple optical system design, precise automatic correction system, combined with the well-designed human-
machine interface to simplify the complexity of machine commissioning and use, ensuring the simple operation and the machine is easy to learn and use.
After Sales Services
Before sale:
We will provide detailed solutions for your special requirement and help you know more about our color sorter.
After sale:
We will test your products at your plant, training your stuff, set every file for customer to serve all round service, so as to ensure your machine working under the best situations.
We provide lifelong software upgrade services for our customers for free.
From the date of purchase machine, we can provide one year free maintenance ( not the reason of vandalism and something unexpected, excluding delicate fittings).
Engineers available to service machinery overseas, we also can train technical stuff for customers.
